Old wall shower dribbling or crusted with scale? The Raymor Armada Wall Shower in Chrome is a fixed arm and rose in one piece, so it goes straight onto the existing outlet with no rail, hose or extra holes. The rose sits on a ball joint and swivels in any direction, which lets everyone in the house aim it where they want it. It's a single function head, so there's nothing to fiddle with. The arm reaches 235mm from the wall, enough to clear your head without hugging the tiles. The body is brass under a chrome plated finish that copes with daily cleaning. WELS 3 star rated at 9 litres a minute. Backed by a 20 year warranty on the brass body, arm, showerhead and the chrome finish, with 1 year on seals and labour.

• Fixed arm and swivel rose in a single unit, so it fits an existing wall outlet with no extra holes
• Ball joint rose that swivels in every direction for a quick change of angle
• 235mm reach from the wall, which gives you room to stand under it comfortably
• Brass construction under a chrome plated finish that stands up to years of cleaning
• Single function spray, so there is nothing to adjust and nothing to go wrong
• WELS 3 star at 9 litres a minute for a decent flow without wasting water
• 20 year warranty on the brass body, arm, showerhead and chrome finish

Wall mounted onto a standard shower outlet. Check the existing arm height suits you, and ask your plumber to fit it if you're not confident with thread tape.

Pair it with Armada tapware and accessories in Chrome to finish the room.

Specifications

WELS water efficiency: 3 star
WELS water consumption: 9.0 L/Min
WELS registration number: S18590
Construction material: Brass
Arm reach: 235mm
Overall height: 235 mm
Country of origin: China
Warranty: 20 Years main brass body, wall elbow, shower arm, shower rail, PVC coated hose, showerhead, handpiece, slide bracket, diverter assembly, soap dish, and chrome plated finish. 5 Years PVD and electroplate finishes. 1 Years seals and Labour

What's In The Box

• Wall shower
• Installation Instructions

Need something solid to hold onto beside the toilet or in the shower? The Raymor Care Grab Rail Straight 300mm in Brushed Stainless Steel is a straight 32mm rail in 304 grade stainless steel, made to meet AS 1428.1:2021, so it suits accessible bathrooms at home and commercial fit-outs alike. Clam flanges hide the screw heads, and 55mm of wall clearance leaves room for a firm grip. Overall width is 378mm across the flanges. Stainless steel screws and installation instructions come in the box. Backed by a 20 year warranty on mechanical parts for domestic installs, 7 years for commercial. Also available in Polished Stainless Steel.

• 304 grade stainless steel, so it won't corrode in a wet area
• 32mm rail with 55mm wall clearance for a full, comfortable hold
• Clam flange with a concealed mount, which hides the fixings from view
• Made to meet AS 1428.1:2021 for accessible home and commercial bathrooms, in a brushed stainless steel finish
• 20 year domestic warranty on mechanical parts, 7 years for commercial installs

Grab rails need solid fixing into noggins or a reinforced wall, so have your builder or plumber fit it and confirm the mounting height for your setup.

The Care range also covers longer straight rails, angled rails, shower seats, taps and toilets.

Specifications

Construction material: 304 Stainless Steel
Overall length: 378 mm
Projection: 87 mm
Height: 78 mm
Rail diameter: 32mm
Country of origin: Philippines
Warranty: 20 Years warranty on all mechanical parts for the original purchaser in domestic installations. A 7 Years warranty applies to commercial installations, irrespective of ownership.

What's In The Box

• Rail
• Stainless Steel Fixing Screws
• Installation Instructions

Want a proper rain shower without changing the arm? The Raymor Lavas Round Shower Rose 300mm in Stainless Steel is the rose only, no arm, so it screws onto an existing wall or ceiling arm through a half inch BSP female connection. At 300mm across it gives a wide, even drench. The plate is stainless steel just 2mm thick, so it looks slim from below, with a brass connector at the back and a ball joint to angle it. Single function, with soft silicon nipples you rub to clear scale. WELS 3 star rated at 9 litres a minute. Backed by a 20 year warranty on the showerhead and brass connector, with 1 year on seals and labour.

• 300mm round face for a wide, rain style flow
• Ultra thin 2mm stainless steel plate that looks slim from underneath
• Brass connector with a ball joint, so you can tilt the spray
• Silicon nipples that let you rub off scale rather than scrub
• Half inch BSP female thread to fit a standard Raymor arm
• Stainless steel finish that shrugs off rust and steam
• WELS 3 star at 9 litres a minute, and a 20 year warranty on the head

Rose only, so you'll need a wall or ceiling arm. Check your arm suits a 300mm head, or ask your plumber.

Pair it with a Raymor ceiling dropper or wall arm, and see the Lavas tapware range for the matching look.

Specifications

WELS water efficiency: 3 star
WELS water consumption: 9.0 L/Min
WELS registration number: S18323
Construction material: Stainless Steel
Rose size: 300mm
Inlet connection: 1/2in BSP Female
Overall height: 57.8 mm
Overall width: 300 mm
Country of origin: China
Warranty: 20 Years Main brass body, wall elbow, shower arm, shower rail, PVC coated hose, showerhead, handpiece, slide balcket, diverter assembly, soap dish, and chrome plated finish. 5 Years PVD and electroplate finishes. 1 Years Seals and labour

What's In The Box

• Shower rose
• Install instructions

Sink mixer too low for the way you cook? The Raymor Projix Sink Mixer Gooseneck in Black lifts the spout to 195mm high with a 202mm reach, and it swivels, so there's room for pots and the flow gets to both bowls. It's a pin lever mixer in lead free brass with a 35mm ceramic disc cartridge in a brass housing. It comes fitted with a WELS 6 star 4.5 litre a minute regulator, and there's a 5 star 6.0 litre regulator in the box if you'd rather a fuller stream. Poly braided hoses with a PE-RT liner are supplied. Backed by a 20 year warranty on the body, cartridge, hoses, spout and handle. Also available in Chrome and Brushed Nickel.

• Gooseneck swivel spout, 195mm high with a 202mm reach, for stockpots and double sinks
• Dual rated: WELS 6 star 4.5 litres a minute fitted, 5 star 6.0 litre regulator included
• Lead free brass body in a black finish that stands up to kitchen use
• 35mm ceramic disc cartridge in a brass housing for smooth pin lever control
• Poly braided PE-RT lined flexible hoses ready to connect
• 20 year warranty on the body, cartridge, aerator, hoses, spout and handle

Bench or hob mounted through a single tap hole, for 150 to 500kPa water pressure. Ask your plumber to fit the regulator you prefer.

The standard height Projix sink mixer, basin mixers and spouts are all available in matching finishes.

Specifications

WELS water efficiency: 6 star
WELS water consumption: 4.5 L/Min
WELS registration number: T44090, T44536
Construction material: Lead-Free Brass
Operating mechanism: Ceramic disc with brass housing
Cartridge size: 35mm
Operating pressure: 150 to 500kPa
Height to spout: 195mm
Spout reach: 202mm
Spout function: Swivel
Lead free: Yes
Country of origin: China
Warranty: 20 Years Mixer Cartridge, Body, Aerator, Hoses, Spout, Handle and Chrome Finish. 10 Years Handpieces and pull down hoses. 5 Years PVD and Electroplate finishes. 1 Years Seals and Labour.

What's In The Box

• 1 x Sink Mixer
• Fixing kit
• Installation instructions

Shower over the bath and the diverter has given up? The Raymor Banjo BC Wall Mixer with Diverter in Chrome runs a bath spout and a shower from one point on the wall, and the diverter switches the water between them. It uses the flat mount body with four point fixing that Banjo BC is known for, which is why plumbers reach for it when the job is a replacement rather than a rebuild. The DZR brass body and a 40mm ceramic disc cartridge in a brass housing are built to keep going, and the paddle handle makes temperature easy to set. Backed by a 20 year warranty on the cartridge, body, handle and chrome finish.

• Built in diverter that sends water to the bath spout or the shower, so you only need one mixer
• Flat mount body with four point fixing for a simpler swap on existing plumbing
• DZR brass construction that stands up to Australian water for years
• 40mm ceramic disc cartridge in a brass housing for smooth, drip free control
• Chrome electroplated finish that cleans up with a wipe
• Suits water pressure from 150 to 500kPa
• 20 year warranty on the cartridge, body, handle and chrome finish

Wall mounted, for a bath and shower combination. Ask your plumber to confirm the existing pipe centres suit a flat mount body.

Match it with the Banjo BC basin mixers and sink mixer in Chrome for a consistent look.

Specifications

Construction material: DZR Brass
Operating mechanism: Ceramic disc with brass housing
Cartridge size: 40mm
Operating pressure: 150 to 500kPa
Lead free: Not Required
Country of origin: China
Warranty: 20 years - Mixer Cartridge, Body, Aerator, Hoses, Spout, Handle and Chrome Finish. 10 years - Handpieces and pull-down hoses. 5 years - PVD and Electroplate finishes. 1 year - Seals and Labour.

What's In The Box

• 1 x Wall mixer
• Fixing kit
• Installation instructions

Freestanding bath waiting on a filler? The Raymor Sturt Round Bath Filler with Hand Shower in Chrome is a floor-standing filler for freestanding baths, with the outlet sitting 976mm off the floor so it clears most bath rims. The 250mm gooseneck spout swivels, and a push pull diverter sends water to the hand shower for rinsing hair or washing the tub down. It's a DZR brass body with a zinc die cast paddle handle and a 40mm ceramic disc cartridge, and the shower hose is PVC coated with dual non return valves fitted. WELS 3 star at 9.0 litres a minute, so a bath fills at a decent pace. Backed by a 15 year warranty on the cartridge, 7 years on the body, spout and handle, and 2 years on seals, fittings and aerators.

• 250mm swivel gooseneck spout that reaches over the rim and swings clear when you're getting in
• Hand shower on a PVC coated hose for rinsing off or washing the bath down
• Push pull diverter to switch between spout and hand shower
• DZR brass body and 40mm ceramic disc cartridge, with a paddle handle for one-hand control
• Dual non return valves in the hose to protect your water supply from backflow
• WELS 3 star at 9.0 litres a minute for a quicker fill
• 15 year warranty on the cartridge, 7 years on body, spout and handle

Floor mounted, 976mm from floor to outlet centre. Your plumber needs the supply lines stubbed up through the floor beside the bath, so plan this before the floor is closed.

See the rest of the Raymor Sturt range in Chrome for matching basin and shower tapware.

Specifications

WELS water efficiency: 3 star
WELS water consumption: 9.0 L/Min
WELS registration number: S09705
Construction material: DZR Brass
Operating mechanism: Ceramic Disc
Spout function: Swivel
Country of origin: China
Warranty: 15 Years ceramic disc cartridge. 10 Years for commercial use. 7 Years body, spout, handle. 2 Years seals, tails, fittings, aerators. 1 Years finish, labour

What's In The Box

• 1 x Round bath filler with hand shower
• Installation Instructions

Old three piece bath set past saving? The Raymor Atlanta Bath Set in Chrome is the traditional three piece setup: separate hot and cold wall taps plus a 165mm fixed spout, for baths with three outlets on the wall. Cross handles in brass give it the classic look that suits older homes and period-style renovations. The bodies are DZR brass under a chrome plated finish, and the taps run on jumper valves, which means a drip is usually fixed with a new washer rather than a new tap. Flow is rated at 6.0 litres a minute. Backed by a 15 year warranty on the bodies, spout, flanges, handles and chrome finish, with 1 year on seals and jumper valves.

• Three piece set: hot tap, cold tap and 165mm fixed spout, so you replace the lot at once
• Brass cross handles that are easy to turn and suit a traditional bathroom
• DZR brass construction that resists corrosion for a long life
• Jumper valve spindles, so servicing is a low-cost washer swap
• Chrome plated finish that wipes clean and matches the Atlanta range
• 6.0 litres a minute flow at the spout
• 15 year warranty on body, spout, flanges, handles, fittings and chrome finish

Wall mounted, for baths with three tap holes. If you're going from a mixer to a set, or the other way, ask your plumber about the wall breeches.

Atlanta also does the matching wall top assemblies, spouts and washing machine stops in Chrome.

Specifications

WELS water consumption: 6.0 L/Min
Construction material: DZR Brass
Operating mechanism: Jumper Valve
Overall height: 61.5 mm
Spout reach: 165mm
Spout function: Fixed
Country of origin: China
Warranty: 15 Years ceramic disc SBAs, spindle SBAs, body, spout, flanges, handles, aerators, fittings and chrome plated finish. 5 Years PVD and electroplate finishes. 1 Years seals, jumper valves and labour

What's In The Box

• 1 x Bath set
• Installation Instructions

Bath spout dripping down the tiles? The Raymor Atlanta Bath Wall Spout 165mm in Chrome is a straight swap for an old wall spout over the bath, and a natural fit if you already have Atlanta taps on the wall. It's a fixed spout in DZR brass with a chrome plated finish, 165mm reach, and a 61mm flange that covers the hole in the tiles. The inlet is a 1/2 inch BSP female thread, which is the standard fitting for a wall breech. It's a plain fixed spout that does one job and keeps doing it. Backed by a 15 year warranty on the body, spout, flange, fittings and chrome finish, with 1 year on seals.

• DZR brass body that resists dezincification, so it lasts in Australian water
• 165mm reach that suits most standard baths
• 61mm flange to hide the tile cut-out behind it
• 1/2 inch BSP female thread for a standard wall connection
• Chrome plated finish that matches Atlanta wall tops and sets
• 15 year warranty on the body, spout, flange, fittings and chrome finish

Wall mounted, 54mm high at the wall. Your plumber will need a breech at the right height above the bath rim, so check it before ordering.

Pair it with Atlanta wall top assemblies, the Atlanta Bath Set or an Atlanta shower to keep the look consistent.

Specifications

Construction material: DZR Brass
Overall height: 54 mm
Height to spout: 54mm
Spout reach: 165mm
Spout function: Fixed
Country of origin: China
Warranty: 15 Years ceramic disc SBAs, spindle SBAs, body, spout, flanges, handles, aerators, fittings and chrome plated finish. 5 Years PVD and electroplate finishes. 1 Years seals, jumper valves and labour

What's In The Box

• 1 x Bath wall spout
• Installation Instructions

Want lever taps over the bath instead of the old cross handles? The Raymor Armada Quarter Turn Bath Set in Chrome is a three piece bath set with a modern twist: lever handles that turn a quarter of the way and stop, with the hot and cold rotating in opposite directions so both feel natural in the hand. Inside are ceramic disc spindles with flat sided assemblies rather than washers, so there's less to wear out. The 127mm aerated spout gives a softer stream at 6.0 litres a minute. Everything is DZR brass with a chrome plated finish. Backed by a 15 year warranty on the ceramic disc spindles, bodies, spout, flanges, handles, aerator and chrome finish, with 1 year on seals.

• Quarter turn lever handles, so full flow is one flick of the wrist
• Contra rotating hot and cold spindles, which means the levers move in mirror image and feel natural
• Ceramic disc spindles with flat sides in place of washers, for years of drip-free use
• 127mm aerated fixed spout that softens the stream and cuts splash
• DZR brass build under a chrome plated finish
• Flows at 6.0 litres a minute
• 15 year warranty covering spindles, body, spout, handles, aerator and the chrome finish

Wall mounted for baths with three tap holes. Ask your plumber to check the breech spacing matches your current set.

Match it with Armada tapware, showers and accessories for the rest of the room.

Specifications

WELS water consumption: 6.0 L/Min
Construction material: DZR Brass
Operating mechanism: Ceramic Disc
Overall height: 65 mm
Spout reach: 127mm
Spout function: Fixed
Country of origin: China
Warranty: 15 Years ceramic disc SBAs, spindle SBAs, body, spout, flanges, handles, aerators, fittings and chrome plated finish. 5 Years PVD and electroplate finishes. 1 Years seals, jumper valves and labour.

What's In The Box

• 1 x Quarter turn bath set
• Installation Instructions

Wall taps over the bath or laundry tub starting to weep? The Raymor Alpha Cross Handle Wall Top Assemblies in Chrome are the hot and cold wall taps on their own, no spout included, so they're the right pick when your existing spout is fine or you're buying one separately. They're a straightforward swap for older wall taps in a bathroom, kitchen or laundry. The rounded Alpha body and cross handles keep the traditional look. Inside you get jumper valves, so a drip means a new washer rather than a plumber's callout for a new set. Made from lead free brass with a chrome electroplated finish. Backed by a 15 year warranty on the body, spindles, flanges, handles and fittings, and 5 years on the finish. Also available in Black and Brushed Nickel.

• Hot and cold wall taps sold as a pair, with no spout, so you only buy what you need
• Jumper valve design for easy washer changes years down the track
• Cross handles with a classic look that are simple to turn
• Lead free brass construction for safer water and a long life
• Chrome electroplated finish that cleans up with a wipe
• Suits bathroom, kitchen and laundry walls, so one set covers most jobs around the house
• 15 year warranty on the body, spindles, flanges, handles and fittings, 5 years on the finish

Wall mounted, for 150 to 500kPa water pressure. Measure the spacing of your existing taps and ask your plumber if you're not sure they'll line up.

Add an Alpha spout, or match them with the Alpha basin set, showers and baths in the same finish.

Specifications

Construction material: Lead-Free Brass
Operating pressure: 150 to 500kPa
Lead free: Yes
Country of origin: China
Warranty: 15 years - ceramic disc SBAs, spindle SBAs, body, spout, flanges, handles, aerators, fittings. 5 years - PVD and electroplate finishes. 1 year - Seals and labour

What's In The Box

• 1 x set hot and cold taps
• Fixing kit
• Installation instructions

Want old-school cross handles on the basin without an old-school drip? The Raymor Alpha Cross Handle Basin Set in Black gives you separate hot and cold taps plus a fixed gooseneck spout, which is the standard layout for basins with three holes. The cross handles and rounded body suit older homes and traditional bathrooms. Both taps use jumper valves, so a drip down the track is a new washer, not a new tap. Lead free brass throughout, under a black electroplated finish. The spout stands 194mm high with a 124mm reach and is WELS 5 star rated at 6.0 litres a minute. Warranty is 15 years on the body, spout, spindles, flanges and handles, with 5 years on the finish. Also available in Chrome and Brushed Nickel.

• Three piece set: hot tap, cold tap and gooseneck spout for basins with three tap holes
• Jumper valve taps, which means a worn washer is a quick, low-cost fix rather than a new tap
• Cross handles that are easy to turn and suit a traditional look
• Fixed gooseneck spout, 194mm high with a 124mm reach, so there's room to wash your hands under it
• WELS 5 star at 6.0 litres a minute for lower water use without a weak flow
• Lead free brass body with a black electroplated finish
• 15 year warranty on the body, spout, spindles, flanges, handles and fittings, 5 years on the finish

Hob mounted, for basins with three tap holes and water pressure between 150 and 500kPa. Not sure your basin has the right spacing? Ask your plumber before you order.

Pair it with the Alpha wall top assemblies, spouts, showers and baths in the same finish.

Specifications

WELS water efficiency: 5 star
WELS water consumption: 6.0 L/Min
WELS registration number: T45416
Construction material: Lead-Free Brass
Operating pressure: 150 to 500kPa
Height to spout: 194mm
Spout reach: 124mm
Lead free: Yes
Country of origin: China
Warranty: 15 years - ceramic disc SBAs, spindle SBAs, body, spout, flanges, handles, aerators, fittings. 5 years - PVD and electroplate finishes. 1 year - Seals and labour

What's In The Box

• 1 x Tap set
• Spout
• Fixing kit
• Installation instructions

Time to swap the stops behind the washing machine? The Raymor Projix Washing Machine Stops in Black replace the wall-mounted hot and cold stops that feed most washing machines. The pin lever handles are quick to grab and give you a clean, modern look in the laundry, and they turn on ceramic disc spindles, so there's no washer to wear out and no slow drip a few years in. The body is lead free brass with a black electroplated finish that copes with a damp laundry. You're covered by a 15 year warranty on the body, spindles, flanges, handles and fittings, with 5 years on the finish. Also available in Chrome.

• Pair of hot and cold wall stops, so you replace the whole set in one go
• Ceramic disc spindles that turn a quarter turn and don't rely on a washer to seal
• Pin lever handles you can flick on and off with wet hands
• Lead free brass body for safer water and years of service
• Black electroplated finish that shrugs off splashes and detergent
• 15 year warranty on the body, spindles, flanges, handles and fittings, 5 years on the finish

Wall mounted, rated for 150 to 500kPa. Check your washing machine hoses will connect to the new stops, and ask your plumber if you're unsure.

Projix also does basin mixers, sink mixers, wall mixers and showers in the same finish if you want the whole house to match.

Specifications

Construction material: Lead-Free Brass
Operating pressure: 150 to 500kPa
Lead free: Yes
Country of origin: China
Warranty: 15 years - ceramic disc SBAs, spindle SBAs, body, spout, flanges, handles, aerators, fittings. 5 years - PVD and electroplate finishes. 1 year - Seals and labour

What's In The Box

• 1 x set stop taps
• Fixing kit
• Installation instructions

Washing machine taps stiff, leaking or just tired? The Raymor Projix Washing Machine Stops in Chrome replace the wall-mounted hot and cold stops that feed most washing machines. The pin lever handles are quick to grab and give you a clean, modern look in the laundry, and they turn on ceramic disc spindles, so there's no washer to wear out and no slow drip a few years in. The body is lead free brass with a chrome electroplated finish that copes with a damp laundry. You're covered by a 15 year warranty on the body, spindles, flanges, handles and fittings, with 5 years on the finish. Also available in Black.

• Pair of hot and cold wall stops, so you replace the whole set in one go
• Ceramic disc spindles that turn a quarter turn and don't rely on a washer to seal
• Pin lever handles you can flick on and off with wet hands
• Lead free brass body for safer water and years of service
• Chrome electroplated finish that shrugs off splashes and detergent
• 15 year warranty on the body, spindles, flanges, handles and fittings, 5 years on the finish

Wall mounted, rated for 150 to 500kPa. Check your washing machine hoses will connect to the new stops, and ask your plumber if you're unsure.

Projix also does basin mixers, sink mixers, wall mixers and showers in the same finish if you want the whole house to match.

Specifications

Construction material: Lead-Free Brass
Operating pressure: 150 to 500kPa
Lead free: Yes
Country of origin: China
Warranty: 15 years - ceramic disc SBAs, spindle SBAs, body, spout, flanges, handles, aerators, fittings. 5 years - PVD and electroplate finishes. 1 year - Seals and labour

What's In The Box

• 1 x set stop taps
• Fixing kit
• Installation instructions

Replacing a wall spout with something sharper? The Raymor Edge II Bath or Basin Spout in Brushed Nickel is a wall mounted spout with the squared profile of the Edge II range, and it suits either a basin or a bath. It's made from lead free brass with a brushed nickel electroplated finish, so it puts up with splashes and cleaning without losing its look. Fitted with a WELS 5 star aerator at 6.0 litres a minute for everyday use, and an open flow aerator comes in the box for filling the bath faster. Team it with an Edge II wall mixer and you have a matching set on the wall. Also available in Chrome and Black.

• Wall mounted spout that works over a basin or a bath, which keeps the look consistent through the bathroom
• Lead free brass body built for years of daily use
• Squared brushed nickel electroplated finish that matches Edge II wall mixers and basin mixers
• WELS 5 star at 6.0 litres a minute to keep water use down at the basin
• Open flow aerator supplied, so you can fill the bath without the wait

Mounts to the wall over a basin or bath and runs on 150 to 500kPa water pressure. Check the reach suits your basin, and ask your plumber if you're unsure.

Edge II also does wall mixers, wall mixer sets, basin mixers, showers and accessories in Brushed Nickel.

Specifications

WELS water efficiency: 5 star
WELS water consumption: 6.0 L/Min
WELS registration number: T43435
Construction material: Lead-Free Brass
Operating pressure: 150 to 500kPa
Lead free: Yes
Country of origin: China
Warranty: 20 years - Mixer Cartridge, Body, Aerator, Hoses, Spout, Handle and Chrome Finish. 10 years - Handpieces and pull-down hoses. 5 years - PVD and Electroplate finishes. 1 year - Seals and Labour

What's In The Box

• 1 x Spout
• Fixing kit
• Installation instructions

Fitting a square basin on top of the vanity? The Raymor Edge II Basin Tower Mixer in Brushed Nickel is the extended height version of the Edge II basin mixer, built for above-counter basins where the spout has to clear the rim of the bowl. Same squared styling, same paddle handle, just taller. It mounts through a single tap hole in the vanity top. The body is lead free brass under a brushed nickel electroplated finish, and the handle runs a 35mm ceramic disc cartridge for years of smooth, drip-free use. Braided hoses lined with PERT are attached and ready for your plumber. It's WELS 5 star rated at 6.0 litres a minute. Also available in Chrome and Black.

• Taller tower body that clears the rim of a vessel basin sitting on the vanity
• Squared Edge II design with a paddle handle to match the rest of the range
• Lead free brass under a brushed nickel electroplated finish, so it stays looking sharp
• 35mm ceramic disc cartridge that keeps the handle light and the spout drip-free
• PERT lined braided hoses fitted, saving time on the install
• WELS 5 star at 6.0 litres a minute for lower water use at the basin

Suits hob mounted vessel basins with one tap hole and 150 to 500kPa pressure. Check the height against your bowl before you buy, and ask your plumber if it's marginal.

Team it with Edge II bath or basin spouts, wall mixers, showers and accessories in Brushed Nickel.

Specifications

WELS water efficiency: 5 star
WELS water consumption: 6.0 L/Min
WELS registration number: T43433
Construction material: Lead-Free Brass
Operating mechanism: Ceramic Disc
Cartridge size: 35mm
Operating pressure: 150 to 500kPa
Height to spout: 250mm
Spout reach: 170mm
Lead free: Yes
Country of origin: China
Warranty: 20 years - Mixer Cartridge, Body, Aerator, Hoses, Spout, Handle and Chrome Finish. 10 years - Handpieces and pull-down hoses. 5 years - PVD and Electroplate finishes. 1 year - Seals and Labour

What's In The Box

• 1 x Basin Mixer
• Fixing kit
• Installation instructions

Bath or basin, need a spout that does either? The Raymor Projix Basin or Bath Wall Spout 200mm in Brushed Nickel is a fixed spout with a 200mm reach, which lands water in the middle of most basins and clears the rim of a bath. Clean square lines match the Projix pin lever taps. It's lead free brass with a brushed nickel electroplated finish that puts up with daily use. Flow is WELS 5 star at 6.0 litres a minute, sensible for a basin and still enough to fill a bath at a fair pace. Backed by a 15 year warranty on the spout, body and fittings, with 5 years on the electroplated finish. Also available in Chrome and Black.

• 200mm reach that suits basins and baths alike, so one part does both jobs
• Fixed outlet with square styling to match Projix wall tops and basin sets
• Lead free brass body under a brushed nickel electroplated finish
• WELS 5 star rated at 6.0 litres a minute for everyday water savings
• Wall mounted, which keeps the basin or bath edge clear for cleaning
• 15 year warranty on the spout, body, aerators and fittings, 5 years on PVD and electroplated finishes

Wall mounted, for water pressure from 150 to 500kPa. Team it with a pair of wall taps, and ask your plumber to check the outlet height over your bath.

Complete the set with Projix Wall Top Assemblies and the Projix Basin Set in the same finish.

Specifications

WELS water efficiency: 5 star
WELS registration number: T45279
Construction material: Lead-Free Brass
Operating pressure: 150 to 500kPa
Spout reach: 200mm
Spout function: Fixed
Lead free: Yes
Country of origin: China
Warranty: 15 years - ceramic disc SBAs, spindle SBAs, body, spout, flanges, handles, aerators, fittings. 5 years - PVD and electroplate finishes. 1 year - Seals and labour.

What's In The Box

• 1 x Spout
• Fixing kit
• Installation instructions

Refreshing the ensuite over a weekend? The Raymor Edge II Basin Mixer in Brushed Nickel is a squared-off single lever mixer for a basin set into the vanity, and a straight swap for most single hole basins. Clean lines and a flat paddle handle give it a modern look without any fuss. It's built from lead free brass with a brushed nickel electroplated finish, and a 35mm ceramic disc cartridge keeps the handle smooth and the spout drip-free. Nylon braided hoses with a PERT lining are already fitted, which saves your plumber time. WELS 5 star rated at 6.0 litres a minute, so it's easy on the water bill. Also available in Chrome and Black.

• Square profile with a flat paddle handle for a clean, current look on the vanity
• Lead free brass body that's safer for drinking water and lasts
• Tough brushed nickel electroplated finish that shrugs off toothpaste and cleaning
• 35mm ceramic disc cartridge for light, precise control and no dripping
• Braided flexible hoses lined with PERT, fitted at the factory
• WELS 5 star at 6.0 litres a minute, which keeps water use low every time you wash your hands

Hob mounted through a single tap hole, for 150 to 500kPa water pressure. For an above-counter basin, look at the taller Edge II Basin Tower Mixer instead.

Match it with Edge II spouts, sink mixers, wall mixer sets, showers and accessories in Brushed Nickel.

Specifications

WELS water efficiency: 5 star
WELS water consumption: 6.0 L/Min
WELS registration number: T43432
Construction material: Lead-Free Brass
Operating mechanism: Ceramic Disc
Cartridge size: 35mm
Operating pressure: 150 to 500kPa
Height to spout: 250mm
Spout reach: 170mm
Lead free: Yes
Country of origin: China
Warranty: 20 years - Mixer Cartridge, Body, Aerator, Hoses, Spout, Handle and Chrome Finish. 10 years - Handpieces and pull-down hoses. 5 years - PVD and Electroplate finishes. 1 year - Seals and Labour

What's In The Box

• 1 x Basin Mixer
• Fixing kit
• Installation instructions

Tall pots and a short tap don't mix? The Raymor Edge II Sink Mixer with Detachable Veggie Spray in Black stands 519mm high with a 204mm reach, so even a stockpot slides under. The handpiece lifts off its hose to reach the corners of the sink or fill a bucket, and it switches between a single stream and a veggie spray for rinsing produce. The spout swivels. It's hob mounted through a single tap hole, so it replaces most kitchen mixers without new holes. Lead free brass body under a black electroplated finish, and a 35mm ceramic disc cartridge in a brass housing behind the paddle handle. The braided hoses, PERT lined, are attached out of the box. WELS 5 star at 6.0 litres a minute. Also available in Chrome.

• Detachable handpiece with single stream and veggie spray modes for rinsing greens or the sink
• Tall swivel spout, 519mm high with a 204mm reach, so big pots fit underneath
• Lead free brass construction with a black electroplated finish that lasts
• 35mm ceramic disc cartridge in a brass housing for reliable, smooth control
• Nylon braided hoses lined with PERT, fitted ready for your plumber
• WELS 5 star at 6.0 litres a minute, which keeps water use sensible
• Square Edge II styling that lines up with Edge II basin mixers and spouts

Hob mounted through one tap hole, for 150 to 500kPa water pressure. Check the 519mm height clears any window or overhead cupboard first.

Pair it with Edge II basin mixers, wall mixer sets, showers and accessories in Black.

Specifications

WELS water efficiency: 5 star
WELS water consumption: 6.0 L/Min
WELS registration number: T43437
Construction material: Lead-Free Brass
Operating mechanism: Ceramic disc with brass housing
Cartridge size: 35mm
Operating pressure: 150 to 500kPa
Height to spout: 519mm
Spout reach: 204mm
Spout function: Swivel
Lead free: Yes
Country of origin: China
Warranty: 20 years - Mixer Cartridge, Body, Aerator, Hoses, Spout, Handle and Chrome Finish. 10 years - Handpieces and pull-down hoses. 5 years - PVD and Electroplate finishes. 1 year - Seals and Labour

What's In The Box

• 1 x Sink Mixer
• Fixing kit
• Installation instructions

Want a square-lined sink mixer without the pull-out hose? The Raymor Edge II Sink Mixer in Black is a fixed spout kitchen mixer with the square, clean-lined look of the Edge II range. The spout swivels and sits 263mm high with a 204mm reach, so it covers a double bowl sink and leaves room for the washing up. No pull-out hose means less to go wrong. It's hob mounted for a single tap hole, a like-for-like swap for most kitchens and laundries. The paddle handle works a 35mm ceramic disc cartridge in a brass housing, inside a lead free brass body with a black electroplated finish. PERT lined braided hoses are on it already. WELS 5 star rated at 6.0 litres a minute. Also available in Chrome.

• Swivel spout at 263mm high with a 204mm reach, which covers both bowls of a double sink
• Fixed spout with no hose, so there's less to wear out over the years
• Lead free brass body with a black electroplated finish that copes with kitchen grime
• 35mm ceramic disc cartridge in a brass housing for a smooth paddle handle
• Nylon braided hoses lined with PERT, attached and ready to go
• WELS 5 star at 6.0 litres a minute to keep the water bill down

Hob mounted through one tap hole, for 150 to 500kPa water pressure. Need more reach? Look at the Edge II Sink Mixer with Detachable Veggie Spray.

Match it with Edge II basin mixers, spouts and wall mixer sets in Black for the rest of the house.

Specifications

WELS water efficiency: 5 star
WELS water consumption: 6.0 L/Min
WELS registration number: T43436
Construction material: Lead-Free Brass
Operating mechanism: Ceramic disc with brass housing
Cartridge size: 35mm
Operating pressure: 150 to 500kPa
Height to spout: 263mm
Spout reach: 204mm
Spout function: Swivel
Lead free: Yes
Country of origin: China
Warranty: 20 years - Mixer Cartridge, Body, Aerator, Hoses, Spout, Handle and Chrome Finish. 10 years - Handpieces and pull-down hoses. 5 years - PVD and Electroplate finishes. 1 year - Seals and Labour

What's In The Box

• 1 x Sink Mixer
• Fixing kit
• Installation instructions

After a square spout to sit over the basin? The Raymor Edge II Bath or Basin Spout in Black is a wall mounted spout with the squared profile of the Edge II range, and it suits either a basin or a bath. It's made from lead free brass with a black electroplated finish, so it puts up with splashes and cleaning without losing its look. Fitted with a WELS 5 star aerator at 6.0 litres a minute for everyday use, and an open flow aerator comes in the box for filling the bath faster. Team it with an Edge II wall mixer and you have a matching set on the wall. Also available in Chrome and Brushed Nickel.

• Wall mounted spout that works over a basin or a bath, which keeps the look consistent through the bathroom
• Lead free brass body built for years of daily use
• Squared black electroplated finish that matches Edge II wall mixers and basin mixers
• WELS 5 star at 6.0 litres a minute to keep water use down at the basin
• Open flow aerator supplied, so you can fill the bath without the wait

Mounts to the wall over a basin or bath and runs on 150 to 500kPa water pressure. Check the reach suits your basin, and ask your plumber if you're unsure.

Edge II also does wall mixers, wall mixer sets, basin mixers, showers and accessories in Black.

Specifications

WELS water efficiency: 5 star
WELS water consumption: 6.0 L/Min
WELS registration number: T43435
Construction material: Lead-Free Brass
Operating pressure: 150 to 500kPa
Lead free: Yes
Country of origin: China
Warranty: 20 years - Mixer Cartridge, Body, Aerator, Hoses, Spout, Handle and Chrome Finish. 10 years - Handpieces and pull-down hoses. 5 years - PVD and Electroplate finishes. 1 year - Seals and Labour

What's In The Box

• 1 x Spout
• Fixing kit
• Installation instructions

Standard mixer too low for your above-counter bowl? The Raymor Edge II Basin Tower Mixer in Black is the extended height version of the Edge II basin mixer, built for above-counter basins where the spout has to clear the rim of the bowl. Same squared styling, same paddle handle, just taller. It mounts through a single tap hole in the vanity top. The body is lead free brass under a black electroplated finish, and the handle runs a 35mm ceramic disc cartridge for years of smooth, drip-free use. Braided hoses lined with PERT are attached and ready for your plumber. It's WELS 5 star rated at 6.0 litres a minute. Also available in Chrome and Brushed Nickel.

• Taller tower body that clears the rim of a vessel basin sitting on the vanity
• Squared Edge II design with a paddle handle to match the rest of the range
• Lead free brass under a black electroplated finish, so it stays looking sharp
• 35mm ceramic disc cartridge that keeps the handle light and the spout drip-free
• PERT lined braided hoses fitted, saving time on the install
• WELS 5 star at 6.0 litres a minute for lower water use at the basin

Suits hob mounted vessel basins with one tap hole and 150 to 500kPa pressure. Check the height against your bowl before you buy, and ask your plumber if it's marginal.

Team it with Edge II bath or basin spouts, wall mixers, showers and accessories in Black.

Specifications

WELS water efficiency: 5 star
WELS water consumption: 6.0 L/Min
WELS registration number: T43433
Construction material: Lead-Free Brass
Operating mechanism: Ceramic Disc
Cartridge size: 35mm
Operating pressure: 150 to 500kPa
Height to spout: 250mm
Spout reach: 170mm
Lead free: Yes
Country of origin: China
Warranty: 20 years - Mixer Cartridge, Body, Aerator, Hoses, Spout, Handle and Chrome Finish. 10 years - Handpieces and pull-down hoses. 5 years - PVD and Electroplate finishes. 1 year - Seals and Labour

What's In The Box

• 1 x Basin Mixer
• Fixing kit
• Installation instructions

Sink mixer past its best and dripping on the bench? The Raymor Sigma Sink Mixer with Detachable Hose in Brushed Nickel has a tall, soft square spout at 453mm high with a 220mm reach, and the handpiece lifts off on its hose so you can rinse right into the corners of the sink or fill a bucket on the floor. It swivels too. It's hob mounted for a single tap hole, so it goes in where your current mixer sits. Lead free brass body, brushed nickel electroplated finish, and a 35mm ceramic disc cartridge in a brass housing behind the paddle handle. Braided hoses with a PERT lining are fitted. WELS 5 star at 6.0 litres a minute. Backed by a 20 year warranty on the body and cartridge, 10 years on the handpiece and hose. Also available in Chrome and Black.

• Detachable handpiece on a hose for reaching the corners of the sink or filling a mop bucket
• Tall swivel spout at 453mm with a 220mm reach, so stockpots and vases fit with ease
• Soft square Sigma styling that pairs with Sigma tapware, showers, basins and baths
• Lead free brass body with a brushed nickel electroplated finish built for the kitchen
• 35mm ceramic disc cartridge in a brass housing, which keeps the paddle handle smooth for years
• WELS 5 star at 6.0 litres a minute for lower water use without a feeble flow
• 20 year warranty on the body, cartridge, aerator, hoses, spout and handle, 10 years on the handpiece and hose, 5 years on Black and Brushed Nickel finishes and 20 years on the Chrome finish, 1 year on seals and labour

Hob mounted through one tap hole, for 150 to 500kPa water pressure. Check the height clears any overhead cupboard or window sill, and ask your plumber if you're unsure.

The Sigma range also covers tapware, showers, basins and baths in Brushed Nickel.

Specifications

WELS water efficiency: 5 star
WELS water consumption: 6.0 L/Min
WELS registration number: T43338
Construction material: Lead-Free Brass
Operating mechanism: Ceramic disc with brass housing
Cartridge size: 35mm
Operating pressure: 150 to 500kPa
Height to spout: 453mm
Spout reach: 220mm
Spout function: Swivel
Lead free: Yes
Country of origin: China
Warranty: 20 Years Mixer Cartridge, Body, Aerator,. Hoses, Spout, Handle and Chrome Finish. 10 Years Handpieces and pull down hoses. 5 Years PVD and Electroplate finishes. 1 Years Seals and Labour

What's In The Box

• 1 x Sink Mixer
• Fixing kit
• Installation instructions

Kitchen tap not tall enough for the stockpot? The Raymor Sigma Sink Mixer with Detachable Hose in Black has a tall, soft square spout at 453mm high with a 220mm reach, and the handpiece lifts off on its hose so you can rinse right into the corners of the sink or fill a bucket on the floor. It swivels too. It's hob mounted for a single tap hole, so it goes in where your current mixer sits. Lead free brass body, black electroplated finish, and a 35mm ceramic disc cartridge in a brass housing behind the paddle handle. Braided hoses with a PERT lining are fitted. WELS 5 star at 6.0 litres a minute. Backed by a 20 year warranty on the body and cartridge, 10 years on the handpiece and hose. Also available in Chrome and Brushed Nickel.

• Detachable handpiece on a hose for reaching the corners of the sink or filling a mop bucket
• Tall swivel spout at 453mm with a 220mm reach, so stockpots and vases fit with ease
• Soft square Sigma styling that pairs with Sigma tapware, showers, basins and baths
• Lead free brass body with a black electroplated finish built for the kitchen
• 35mm ceramic disc cartridge in a brass housing, which keeps the paddle handle smooth for years
• WELS 5 star at 6.0 litres a minute for lower water use without a feeble flow
• 20 year warranty on the body, cartridge, aerator, hoses, spout and handle, 10 years on the handpiece and hose, 5 years on Black and Brushed Nickel finishes and 20 years on the Chrome finish, 1 year on seals and labour

Hob mounted through one tap hole, for 150 to 500kPa water pressure. Check the height clears any overhead cupboard or window sill, and ask your plumber if you're unsure.

The Sigma range also covers tapware, showers, basins and baths in Black.

Specifications

WELS water efficiency: 5 star
WELS water consumption: 6.0 L/Min
WELS registration number: T43338
Construction material: Lead-Free Brass
Operating mechanism: Ceramic disc with brass housing
Cartridge size: 35mm
Operating pressure: 150 to 500kPa
Height to spout: 453mm
Spout reach: 220mm
Spout function: Swivel
Lead free: Yes
Country of origin: China
Warranty: 20 Years Mixer Cartridge, Body, Aerator,. Hoses, Spout, Handle and Chrome Finish. 10 Years Handpieces and pull down hoses. 5 Years PVD and Electroplate finishes. 1 Years Seals and Labour

What's In The Box

• 1 x Sink Mixer
• Fixing kit
• Installation instructions

Kitchen sink mixer leaking at the base? The Raymor Atlanta Sink Mixer in Brushed Nickel is a gooseneck kitchen mixer with a pin lever handle, in the traditional Atlanta style that suits older homes and country kitchens. The spout swivels and stands 363mm high with a 183mm reach, so there's room to fill a stockpot or rinse a roasting tray. It's hob mounted through one tap hole, a straightforward replacement for most sinks. The body is lead free brass under a brushed nickel electroplated finish, with a 35mm ceramic disc cartridge sitting in a brass housing for a long, drip-free life. Braided flexible hoses with a PERT lining are fitted. WELS 5 star rated at 6.0 litres a minute. Also available in Chrome and Black.

• Gooseneck swivel spout, 363mm high with a 183mm reach, which fits big pots and pans underneath
• Pin lever handle in the classic Atlanta look that's easy to use with wet or soapy hands
• Lead free brass body for safer water and years of service
• Hard-wearing brushed nickel electroplated finish that wipes clean
• 35mm ceramic disc cartridge in a brass housing, so the handle stays smooth and drips stay away
• Nylon braided hoses lined with PERT, already attached for a faster install
• WELS 5 star at 6.0 litres a minute to trim water use at the sink

Suits hob mounted sinks with a single tap hole and 150 to 500kPa water pressure. Not a pull-out, so measure the reach against your sink before ordering.

Match it with Atlanta basin sets, spouts, washing machine stops and wall top assemblies in Brushed Nickel.

Specifications

WELS water efficiency: 5 star
WELS water consumption: 6.0 L/Min
WELS registration number: T43704
Construction material: Lead-Free Brass
Operating mechanism: Ceramic disc with brass housing
Cartridge size: 35mm
Operating pressure: 150 to 500kPa
Height to spout: 363mm
Spout reach: 183mm
Spout function: Swivel
Lead free: Yes
Country of origin: China
Warranty: 20 years - Mixer Cartridge, Body, Aerator, Hoses, Spout, Handle and Chrome Finish. 10 years - Handpieces and pull-down hoses. 5 years - PVD and Electroplate finishes. 1 year - Seals and Labour.

What's In The Box

• 1 x Sink Mixer
• Fixing kit
• Installation instructions

After a classic looking kitchen tap that still does the job? The Raymor Atlanta Sink Mixer in Black is a gooseneck kitchen mixer with a pin lever handle, in the traditional Atlanta style that suits older homes and country kitchens. The spout swivels and stands 363mm high with a 183mm reach, so there's room to fill a stockpot or rinse a roasting tray. It's hob mounted through one tap hole, a straightforward replacement for most sinks. The body is lead free brass under a black electroplated finish, with a 35mm ceramic disc cartridge sitting in a brass housing for a long, drip-free life. Braided flexible hoses with a PERT lining are fitted. WELS 5 star rated at 6.0 litres a minute. Also available in Chrome and Brushed Nickel.

• Gooseneck swivel spout, 363mm high with a 183mm reach, which fits big pots and pans underneath
• Pin lever handle in the classic Atlanta look that's easy to use with wet or soapy hands
• Lead free brass body for safer water and years of service
• Hard-wearing black electroplated finish that wipes clean
• 35mm ceramic disc cartridge in a brass housing, so the handle stays smooth and drips stay away
• Nylon braided hoses lined with PERT, already attached for a faster install
• WELS 5 star at 6.0 litres a minute to trim water use at the sink

Suits hob mounted sinks with a single tap hole and 150 to 500kPa water pressure. Not a pull-out, so measure the reach against your sink before ordering.

Match it with Atlanta basin sets, spouts, washing machine stops and wall top assemblies in Black.

Specifications

WELS water efficiency: 5 star
WELS water consumption: 6.0 L/Min
WELS registration number: T43704
Construction material: Lead-Free Brass
Operating mechanism: Ceramic disc with brass housing
Cartridge size: 35mm
Operating pressure: 150 to 500kPa
Height to spout: 363mm
Spout reach: 183mm
Spout function: Swivel
Lead free: Yes
Country of origin: China
Warranty: 20 years - Mixer Cartridge, Body, Aerator, Hoses, Spout, Handle and Chrome Finish. 10 years - Handpieces and pull-down hoses. 5 years - PVD and Electroplate finishes. 1 year - Seals and Labour.

What's In The Box

• 1 x Sink Mixer
• Fixing kit
• Installation instructions

Replacing a tired kitchen mixer this weekend? The Raymor Projix Pull-Out Sink Mixer in Brushed Nickel has a swivel spout and a handpiece that pulls out on a hose, so rinsing the sink or filling a pot on the bench is no drama. At 377mm high with a 190mm reach it sits well over most single and double bowl sinks. It's a hob mounted mixer for a single tap hole, a direct swap for most kitchens. The body is lead free brass with a brushed nickel electroplated finish, and the pin lever handle runs a 35mm ceramic disc cartridge in a brass housing. Braided hoses with a PERT lining come fitted. WELS 5 star at 6.0 litres a minute. Backed by a 20 year warranty on the body and cartridge, and 10 years on the handpiece and hose. Also available in Chrome and Black.

• Pull-out handpiece on a hose, so you can rinse the whole sink and fill pots off to the side
• Swivel spout, 377mm high with a 190mm reach, which gives plenty of room under the outlet
• Pin lever handle on a 35mm ceramic disc cartridge in a brass housing for smooth, precise control
• Lead free brass body with a brushed nickel electroplated finish that stands up to daily kitchen use
• Nylon braided flexible hoses lined with PERT, fitted ready for your plumber
• WELS 5 star at 6.0 litres a minute to keep the water bill in check
• 20 year warranty on the body, cartridge, aerator, hoses, spout and handle, 10 years on the handpiece and pull-down hose, 5 years on Black and Brushed Nickel finishes and 20 years on the Chrome finish, 1 year on seals and labour

Hob mounted through one tap hole, for 150 to 500kPa water pressure. Check there's space under the bench for the hose to drop, and ask your plumber if you're unsure.

Projix also does straight spouts, bath spouts and wall mixers in Brushed Nickel to match.

Specifications

WELS water efficiency: 5 star
WELS water consumption: 6.0 L/Min
WELS registration number: T43337
Construction material: Lead-Free Brass
Operating mechanism: Ceramic disc with brass housing
Cartridge size: 35mm
Operating pressure: 150 to 500kPa
Height to spout: 377mm
Spout reach: 190mm
Spout function: Swivel
Lead free: Yes
Country of origin: China
Warranty: 20 Years Mixer Cartridge, Body, Aerator,. Hoses, Spout, Handle and Chrome Finish. 10 Years Handpieces and pull down hoses. 5 Years PVD and Electroplate finishes. 1 Years Seals and Labour

What's In The Box

• 1 x Sink Mixer
• Fixing kit
• Installation instructions

After a pull-out sink mixer that won't break the bank? The Raymor Projix Pull-Out Sink Mixer in Black has a swivel spout and a handpiece that pulls out on a hose, so rinsing the sink or filling a pot on the bench is no drama. At 377mm high with a 190mm reach it sits well over most single and double bowl sinks. It's a hob mounted mixer for a single tap hole, a direct swap for most kitchens. The body is lead free brass with a black electroplated finish, and the pin lever handle runs a 35mm ceramic disc cartridge in a brass housing. Braided hoses with a PERT lining come fitted. WELS 5 star at 6.0 litres a minute. Backed by a 20 year warranty on the body and cartridge, and 10 years on the handpiece and hose. Also available in Chrome and Brushed Nickel.

• Pull-out handpiece on a hose, so you can rinse the whole sink and fill pots off to the side
• Swivel spout, 377mm high with a 190mm reach, which gives plenty of room under the outlet
• Pin lever handle on a 35mm ceramic disc cartridge in a brass housing for smooth, precise control
• Lead free brass body with a black electroplated finish that stands up to daily kitchen use
• Nylon braided flexible hoses lined with PERT, fitted ready for your plumber
• WELS 5 star at 6.0 litres a minute to keep the water bill in check
• 20 year warranty on the body, cartridge, aerator, hoses, spout and handle, 10 years on the handpiece and pull-down hose, 5 years on Black and Brushed Nickel finishes and 20 years on the Chrome finish, 1 year on seals and labour

Hob mounted through one tap hole, for 150 to 500kPa water pressure. Check there's space under the bench for the hose to drop, and ask your plumber if you're unsure.

Projix also does straight spouts, bath spouts and wall mixers in Black to match.

Specifications

WELS water efficiency: 5 star
WELS water consumption: 6.0 L/Min
WELS registration number: T43337
Construction material: Lead-Free Brass
Operating mechanism: Ceramic disc with brass housing
Cartridge size: 35mm
Operating pressure: 150 to 500kPa
Height to spout: 377mm
Spout reach: 190mm
Spout function: Swivel
Lead free: Yes
Country of origin: China
Warranty: 20 Years Mixer Cartridge, Body, Aerator,. Hoses, Spout, Handle and Chrome Finish. 10 Years Handpieces and pull down hoses. 5 Years PVD and Electroplate finishes. 1 Years Seals and Labour

What's In The Box

• 1 x Sink Mixer
• Fixing kit
• Installation instructions

Bath spout gone dull or dripping at the wall? The Raymor Edge II Bath or Basin Spout in Chrome is a wall mounted spout with the squared profile of the Edge II range, and it suits either a basin or a bath. It's made from lead free brass with a chrome electroplated finish, so it puts up with splashes and cleaning without losing its look. Fitted with a WELS 5 star aerator at 6.0 litres a minute for everyday use, and an open flow aerator comes in the box for filling the bath faster. Team it with an Edge II wall mixer and you have a matching set on the wall. Also available in Black and Brushed Nickel.

• Wall mounted spout that works over a basin or a bath, which keeps the look consistent through the bathroom
• Lead free brass body built for years of daily use
• Squared chrome electroplated finish that matches Edge II wall mixers and basin mixers
• WELS 5 star at 6.0 litres a minute to keep water use down at the basin
• Open flow aerator supplied, so you can fill the bath without the wait

Mounts to the wall over a basin or bath and runs on 150 to 500kPa water pressure. Check the reach suits your basin, and ask your plumber if you're unsure.

Edge II also does wall mixers, wall mixer sets, basin mixers, showers and accessories in Chrome.

Specifications

WELS water efficiency: 5 star
WELS water consumption: 6.0 L/Min
WELS registration number: T43435
Construction material: Lead-Free Brass
Operating pressure: 150 to 500kPa
Lead free: Yes
Country of origin: China
Warranty: 20 years - Mixer Cartridge, Body, Aerator, Hoses, Spout, Handle and Chrome Finish. 10 years - Handpieces and pull-down hoses. 5 years - PVD and Electroplate finishes. 1 year - Seals and Labour

What's In The Box

• 1 x Spout
• Fixing kit
• Installation instructions

Need to rinse the far side of the sink without a jug? The Raymor Edge II Sink Mixer with Detachable Veggie Spray in Chrome stands 519mm high with a 204mm reach, so even a stockpot slides under. The handpiece lifts off its hose to reach the corners of the sink or fill a bucket, and it switches between a single stream and a veggie spray for rinsing produce. The spout swivels. It's hob mounted through a single tap hole, so it replaces most kitchen mixers without new holes. Lead free brass body under a chrome electroplated finish, and a 35mm ceramic disc cartridge in a brass housing behind the paddle handle. The braided hoses, PERT lined, are attached out of the box. WELS 5 star at 6.0 litres a minute. Also available in Black.

• Detachable handpiece with single stream and veggie spray modes for rinsing greens or the sink
• Tall swivel spout, 519mm high with a 204mm reach, so big pots fit underneath
• Lead free brass construction with a chrome electroplated finish that lasts
• 35mm ceramic disc cartridge in a brass housing for reliable, smooth control
• Nylon braided hoses lined with PERT, fitted ready for your plumber
• WELS 5 star at 6.0 litres a minute, which keeps water use sensible
• Square Edge II styling that lines up with Edge II basin mixers and spouts

Hob mounted through one tap hole, for 150 to 500kPa water pressure. Check the 519mm height clears any window or overhead cupboard first.

Pair it with Edge II basin mixers, wall mixer sets, showers and accessories in Chrome.

Specifications

WELS water efficiency: 5 star
WELS water consumption: 6.0 L/Min
WELS registration number: T43437
Construction material: Lead-Free Brass
Operating mechanism: Ceramic disc with brass housing
Cartridge size: 35mm
Operating pressure: 150 to 500kPa
Height to spout: 519mm
Spout reach: 204mm
Spout function: Swivel
Lead free: Yes
Country of origin: China
Warranty: 20 years - Mixer Cartridge, Body, Aerator, Hoses, Spout, Handle and Chrome Finish. 10 years - Handpieces and pull-down hoses. 5 years - PVD and Electroplate finishes. 1 year - Seals and Labour

What's In The Box

• 1 x Sink Mixer
• Fixing kit
• Installation instructions

Kitchen mixer leaking and the cupboard under the sink getting damp? The Raymor Edge II Sink Mixer in Chrome is a fixed spout kitchen mixer with the square, clean-lined look of the Edge II range. The spout swivels and sits 263mm high with a 204mm reach, so it covers a double bowl sink and leaves room for the washing up. No pull-out hose means less to go wrong. It's hob mounted for a single tap hole, a like-for-like swap for most kitchens and laundries. The paddle handle works a 35mm ceramic disc cartridge in a brass housing, inside a lead free brass body with a chrome electroplated finish. PERT lined braided hoses are on it already. WELS 5 star rated at 6.0 litres a minute. Also available in Black.

• Swivel spout at 263mm high with a 204mm reach, which covers both bowls of a double sink
• Fixed spout with no hose, so there's less to wear out over the years
• Lead free brass body with a chrome electroplated finish that copes with kitchen grime
• 35mm ceramic disc cartridge in a brass housing for a smooth paddle handle
• Nylon braided hoses lined with PERT, attached and ready to go
• WELS 5 star at 6.0 litres a minute to keep the water bill down

Hob mounted through one tap hole, for 150 to 500kPa water pressure. Need more reach? Look at the Edge II Sink Mixer with Detachable Veggie Spray.

Match it with Edge II basin mixers, spouts and wall mixer sets in Chrome for the rest of the house.

Specifications

WELS water efficiency: 5 star
WELS water consumption: 6.0 L/Min
WELS registration number: T43436
Construction material: Lead-Free Brass
Operating mechanism: Ceramic disc with brass housing
Cartridge size: 35mm
Operating pressure: 150 to 500kPa
Height to spout: 263mm
Spout reach: 204mm
Spout function: Swivel
Lead free: Yes
Country of origin: China
Warranty: 20 years - Mixer Cartridge, Body, Aerator, Hoses, Spout, Handle and Chrome Finish. 10 years - Handpieces and pull-down hoses. 5 years - PVD and Electroplate finishes. 1 year - Seals and Labour

What's In The Box

• 1 x Sink Mixer
• Fixing kit
• Installation instructions

Vessel basin waiting on a tap that's tall enough? The Raymor Edge II Basin Tower Mixer in Chrome is the extended height version of the Edge II basin mixer, built for above-counter basins where the spout has to clear the rim of the bowl. Same squared styling, same paddle handle, just taller. It mounts through a single tap hole in the vanity top. The body is lead free brass under a chrome electroplated finish, and the handle runs a 35mm ceramic disc cartridge for years of smooth, drip-free use. Braided hoses lined with PERT are attached and ready for your plumber. It's WELS 5 star rated at 6.0 litres a minute. Also available in Black and Brushed Nickel.

• Taller tower body that clears the rim of a vessel basin sitting on the vanity
• Squared Edge II design with a paddle handle to match the rest of the range
• Lead free brass under a chrome electroplated finish, so it stays looking sharp
• 35mm ceramic disc cartridge that keeps the handle light and the spout drip-free
• PERT lined braided hoses fitted, saving time on the install
• WELS 5 star at 6.0 litres a minute for lower water use at the basin

Suits hob mounted vessel basins with one tap hole and 150 to 500kPa pressure. Check the height against your bowl before you buy, and ask your plumber if it's marginal.

Team it with Edge II bath or basin spouts, wall mixers, showers and accessories in Chrome.

Specifications

WELS water efficiency: 5 star
WELS water consumption: 6.0 L/Min
WELS registration number: T43433
Construction material: Lead-Free Brass
Operating mechanism: Ceramic Disc
Cartridge size: 35mm
Operating pressure: 150 to 500kPa
Height to spout: 110mm
Spout reach: 120mm
Lead free: Yes
Country of origin: China
Warranty: 20 years - Mixer Cartridge, Body, Aerator, Hoses, Spout, Handle and Chrome Finish. 10 years - Handpieces and pull-down hoses. 5 years - PVD and Electroplate finishes. 1 year - Seals and Labour

What's In The Box

• 1 x Basin Mixer
• Fixing kit
• Installation instructions

Like the Alpha look but want a lever you can flick? The Raymor Alpha Lever Handle Wall Top Assemblies in Brushed Nickel are a hot and cold pair for the wall, with rounded lever handles that you can work with a wrist or the back of a hand. No spout comes with them, which makes them the right pick when you're replacing just the taps or pairing with a separate Alpha spout. Ceramic discs inside mean a short, smooth turn and no washers to change down the track. The bodies are lead free brass finished in brushed nickel electroplate. Backed by a 15 year warranty on the ceramic disc assemblies, body, flanges, handles and fittings. Also available in Chrome and Black.

• Lever handles that need little grip, handy for kids and anyone with stiff hands
• Hot and cold wall taps sold as a pair, with the spout bought separately
• Ceramic disc action for a smooth turn and no drips
• Lead free brass body built to last
• Brushed nickel electroplated finish that ties in with Alpha spouts and basin sets
• 15 year warranty on the ceramic disc and spindle assemblies, body, flanges and handles, plus 5 years on the finish

Wall mounted, suited to 150 to 500kPa water pressure. Ask your plumber to confirm the breech spacing matches your existing taps.

Team them with an Alpha Basin or Bath Wall Spout 200mm, or go the Alpha Lever Handle Basin Set for the vanity.

Specifications

Construction material: Lead-Free Brass
Operating pressure: 150 to 500kPa
Lead free: Yes
Country of origin: China
Warranty: 15 years - ceramic disc SBAs, spindle SBAs, body, spout, flanges, handles, aerators, fittings. 5 years - PVD and electroplate finishes. 1 year - Seals and labour

What's In The Box

• 1 x set hot and cold taps
• Fixing kit
• Installation instructions
