Setting up an accessible bathroom? The Caroma Care 400 Connector Suite with Backrest has a Caravelle Care single flap seat in White, and an extended flush pipe at mid level joins the cistern to the pan. The Trident care pan has a concealed S-trap at a 300mm set out, and the raised seat sits 460 to 480mm high. The Sovereign care cistern is vitreous china with a bottom inlet and raised chrome push buttons that are easy to reach. A stainless steel backrest comes in the box. Caroma states it meets AS 1428.1-2009 Amd 1 for access and mobility, and it's WELS 4 star on a 4.5/3L dual flush. Warranty is 20 years on product replacement and 1 year on parts and labour. Also available in Anthracite Grey.
- Single flap Caravelle Care seat in white, on a white vitreous china pan and cistern
- Raised seat height of 460 to 480mm, which makes sitting and standing easier
- Stainless steel backrest included for extra support
- Raised chrome push buttons that are easy to find and press
- Concealed S-trap at a fixed 300mm set out, so measure before ordering
- Caroma states it meets AS 1428.1-2009 Amd 1 for access and mobility
- WELS 4 star dual flush at 4.5/3L, averaging 3.5 litres, to save water
This suite needs a 300mm S-trap set out and a bottom water inlet, so check both with your plumber. It's fragile and may need a two-person lift.
Add Caroma Care grab rails and a support shower set to complete the room.
Specifications
dimensions (W x D x H): 450 x 800 x 1100mm
seat height: 460-480mm (raised)
trap: S-trap (concealed)
set out: 300mm (min and max)
flush: Dual flush 4.5/3L, 3.5L average
WELS rating: 4 Star
WELS registration no: L03407
WaterMark: Yes (certified; number not stated)
material: Vitreous china
compliance: AS1428.1-2009 Amd.1
warranty: 20 years product replacement; 1 year parts and labour
care: Clean with mild household detergent or warm soapy water and a soft cloth.
country of origin/manufacture: China
handling: 2 person lift may be required; fragile
colour: White (pan/cistern and seat)
seat: Caravelle Care single flap seat, white
weight: 38.32kg
tradelink item: 125336
What's In The Box
- pan
- cistern
- Caravelle Care single flap seat (white)
- stainless steel backrest
- extended mid-level flush pipe
- raised height care buttons
